Flexible PCB Circuit Board Double Sided FPC Manufacturer for Digital Camera
Product Description
Min Order Quantity：1 Piece
Supply Ability：60000 pieces per month
Port：SHENZHEN
Delivery Lead Time：14 working days
Country/Region：China
City：Shenzhen
Product Attributes
- - Model Number BIC-0333-V1.0
- - Place of Origin China
- - Supply Type OEM Service
- - Condition New
- - Color Yellow
- - Base Material Polyimide
- - Board Thickness 0.15mm
- - Copper Thickness 1oz
- - Min. Hole Size 0.3mm
- - Min. Line Spacing 4mil
- - Min. Line Width 4mil
- - Surface Finishing ENIG
- - Related Keywords Flexible PCB, Flexible circuit, FPC
Description by Manufacturer
Flexible PCB Circuit Board Double Sided FPC Manufacturer for Digital Camera (Flexible printed circuits are custom-made products, the picture and parameters shown are just for reference)
PCB Specifications
| PCB SIZE | 107 x 89mm=1PCS |
| Base Material: | Polyimide |
| Number of Layers | Double sided PCB |
| SMT | YES |
| Through Hole Components | no |
| LAYER STACKUP | Copper ------- 35um(1oz) |
| Adhesive | |
| Polyimide | |
| TECHNOLOGY | |
| Minimum Trace and Space: | 4mil/4mil |
| Minimum / Maximum Holes: | 0.3mm/ 1.5mm |
| Final foil external: | 1oz |
| Final foil internal: | 0oz |
| Final height of PCB: | 0.15mm ±0.05 |
| Surface Finish | Immersion gold |
| Solder Mask Apply To: | TOP, Bottom |
| Solder Mask Color: | Yellow Coverlay |
| CONTOUR/CUTTING | Punching |
| Side of Component Legend | TOP, Bottom |
| Colour of Component Legend | White |
| VIA | Plated Through Hole(PTH) |
| FLAMIBILITY RATING | UL 94-V0 Approval MIN. |
| TEST | 100% Electrical Test prior shipment |
| TYPE OF ARTWORK TO BE SUPPLIED | email file, Gerber RS-274-X, PCBDOC etc |
| SERVICE AREA | Worldwide, Globally. |
FPC Capabilities 2021
| No. | Specifications | Capabilities |
| 1 | Board Type | Single layer, Doulbe layer, Multilayer, Rigid-Flex |
| 2 | Base Material | PI, PET |
| 3 | Copper Weight | 0.5oz, 1oz, 2oz |
| 4 | LED Maximum Size | 250 x 5000mm |
| 5 | General Maximum Size | 250 x 2000mm |
| 6 | Board Thickness | 0.03mm-3.0mm |
| 7 | Thickness Tolerance | ±0.03mm |
| 8 | Mininum Drill Hole | 0.05mm |
| 9 | Maximum Drill Hole | 6.5mm |
| 10 | Tolerance of Drill Hole | ±0.025mm |
| 11 | Thickness of Hole Wall | ≧ 8 um |
| 12 | Minimum Track/Gap of Single Layer Board | 0.025/0.03mm |
| 13 | Minimum Track/Gap of Double Layer and Multilayer Board | 0.03/0.040mm |
| 14 | Etching Tolerance | ±0.02mm |
| 15 | Minimum Width of Silk Legend | ≧ 0.125mm |
| 16 | Minimum Heigh of Silk Legend | ≧ 0.75mm |
| 17 | Distance from Legend to Pad | ≧ 0.15mm |
| 18 | Distance from Opening Solder Mask of Drill Coverlay to Track | ≧ 0.03mm |
| 19 | Distance from Opening Solder Mask of Punching Coverlay to Track | ≧ 0.03mm |
| 20 | Thickness of Immersion Nickel | 100-300u" |
| 21 | Thickness of Immersion Gold | 1-3u" |
| 22 | Thicnkess of Immersion Tin | 150-400u" |
| 23 | Minimum Electrical Testing Pad | 0.2mm |
| 24 | Minimum Tolerance of Outline(Normal Steel Mould Punch) | ±0.1mm |
| 25 | Minimum Tolerance of Outline (Precision Steel Mould Punch) | ±0.05mm |
| 26 | Mininum Radius of Bevel Angle (Outline) | 0.2mm |
| 27 | Stiffner Material | PI, FR-4, 3M Adhesive, PET, Steel Sheet |
| 28 | RoHs | Yes |
| 29 | Solder Mask Colour | Yellow, White, Black, Green |
Price
- Price US$ \ 2.99 ~ 8.99 / Piece
Packaging & Shipping
- - Packing100pieces
- - Packaging Size36 x 36 x 20 ( Centimeters)
- - Package Weight 10 ( Kilograms )
- - Delivery Lead Time14 working days
- - Minimum Order 1 Piece
- - Supply Ability60000 pieces per month
- - Total quantity in StockOver 5000
- - Delivery PortSHENZHEN
- - HS Code8534009000
- - Shipping Career
