6x4 10 Wheels Howo Sinotruk Dump Truck
Dump truck is a vehicle that unloads goods by itself through hydraulic or mechanical lifting. Also known as dumper truck. It is composed of automobile chassis, hydraulic lifting mechanism, cargo compartment and force taking device.
Product Description
The sinotruk Howo 6x4 dump truck controlled by the hydraulic lifting mechanism can be disassembled or tilted at a certain angle to realize self-unloading or horizontal push unloading. Exquisite design, excellent technology, comfortable, safe, reliable, low fuel consumption, widely used in mines, construction sites to transport bulk loose materials (such as sand, soil, minerals, etc.) or integrated materials. It can be divided into special dump trucks, ordinary dump trucks and mining dump trucks.
As a professional dump truck supplier, Luyi provides Howo dump trucks include: sinotruck HOWO 336hp 6X4 10 wheel 16 cubic meters dump truck, sino truck 371hp 10 wheeler 30 tons 20 cubic meters dump truck, SINOTRUK howo 8X4 12 wheeler 40tons end dump truck and so on.
Product details
Luyi Vehicle side wall semi trailer can be designed according to different needs of customers, or tell us your different media cargoes, we will design come to you to design the corresponding models, to make your transportation much more economical.
Sinotruk Howo 6x4 dump truck advantages:
• Competitive price, cost-effective.
• Low fuel consumption, powerful enough engine.
• The cab is beautiful in appearance, safe and reliable.
• Using high-strength steel, the service life is long.
• Fast and efficient spare parts supply brings you convenience
• Various truck models, can meet your customized requirements.
• Strong technical support makes the truck higher quality and more reliable.
• Various cargo box structures, light weight, good rigidity and strong bearing capacity.
• Imported hydraulic control system to avoid misoperation, higher safety and operating efficiency.
• Fast delivery time, the production can be arranged accurately and quickly according to your needs.
Parameter
|
Basic Information |
|
|
Announcement model： |
ZZ3257N3647C |
|
Loading capacity |
20 cbm(18cbm optional) |
|
Drive form： |
6X4 |
|
Wheelbase： |
3625+1350mm |
|
Engine： |
Sinotruk WD615.96C |
|
Gearbox： |
Sinotruk HW19710 |
|
Rear axle speed ratio： |
5.45 |
|
Length： |
8.6m |
|
Width： |
2.5m |
|
Height： |
1.7m |
|
wheel track： |
Front track：2022mm；track rear：1830/1830mm |
|
Vehicle weight |
12.29 ton |
|
Loading capacity |
30 ton |
|
Gross mass： |
25 ton |
|
Approach angle： |
19° |
|
Departure angle： |
26° |
|
Engine： |
|
|
Engine： |
Sinotruk WD615.96C |
|
|
Number of cylinders： |
6 |
|
|
Type of fuel： |
diesel |
||
|
Displacement： |
9.726L |
||
|
Emission standard： |
Euro2 |
||
|
Horsepower： |
375hp/371HP |
||
|
Maximum output： |
276kW |
||
|
Torque： |
1500N·m |
||
|
Speed at maximum torque ： |
1100-1600rpm |
||
|
rated speed： |
2200rpm |
||
|
Engine form： |
Six cylinder inline |
||
|
Box parameter |
|
||
|
Box length： |
5.6m |
||
|
Box width ： |
2.3m |
||
|
Box height： |
1.5m |
||
|
Box type： |
rear dump |
||
|
Gearbox |
|
||
|
Gearbox： |
Sinotruk HW19710 |
||
|
Forward gears： |
10 |
||
|
Reverse gears： |
2 |
||
|
Tyre |
|
||
|
Tyre Type： |
12.00-20 |
||
|
Number of tires： |
10 |
||
|
fuel tank |
|
||
|
capacity of tank ： |
400L |
||
|
chassis |
|
||
|
Rear axle description： |
STR16 / AC16 |
||
|
Rear axle allowable load： |
16000kg |
||
|
Rear axle ratio： |
5.45 |
||
|
Spring leaf number： |
10/12 |
Customer praise
Luyi brand has served more than 80 countries including Germany, Australia, Africa, Africa, southeast Asia, the Middle East, South Africa, South America, etc., and has established 78 service points in 50 major market countries.In particular, Luyi oil tanker obtained approval through ADR standard, serving more than 20 countries including Sinopec, Petrochina, shell and Castrol. Luyi brand stands tall in Shandong of China "qilu land", do the industry first. Therefore, Luyi serves global customers with exceptional product quality and goes global.
If you are looking for high quality Howo dump trucks with custom service and low cost price, welcome to contact us!
