SHACMAN DUMP TRUCK
SHACMAN DUMP TRUCK
Product Description
Luyi is professional supplier for Truck head, dump truck models include: Shacman 380hp,430hp
SHACMAN F3000 10 Wheeler tipper 30 Tons 6x4 Dump Truck Price
|
Model |
SX3255DT384 |
|
|
Cabin |
Hydraulic suspension F3000 cab, Safety belt, Adjustable steering, Sleeper, A/C |
|
|
Engine |
Type: Diesel 4-stoke Direct injection,6-cylinder in line, Turbo-charging, Inner cooling. |
|
|
Model: |
WP10.380E22 |
WEICHAI with MAN EVB technology |
|
|
Displacement(L): |
9.726liter |
|
|
Max torque: |
1600NM@1500-1800rpm |
|
|
Bore/stoke: |
126mm/130mm |
|
|
Fuel consumption: |
<196g /kwh |
|
Gear box |
American technology |
Max torque:1800NM |
|
|
Model: |
FAST 10JSD180+QH50 |
|
|
Speed: |
10 speed, 2 reverse |
|
Axle(front/rear) |
||
|
Front axle |
9.5T MAN technology non-driving steering axle |
|
|
Tandem |
16T MAN technology double reduction, hub redactor driving axle, ratio: 5.92 |
|
|
Clutch |
D430 diaphragm type, single dry frictional disc, hydraulic boosting |
|
|
Brake |
Service brake: Double circuit pneumatic brake |
|
|
|
Parking brake: Spring-Power drum brake |
|
|
|
Engine brake: Engine exhaust brake (EVB) |
|
|
Steering |
ZF technology, driver sit at the left hand side |
|
|
Electric Equipment |
||
|
|
Operating voltage: |
24V negative grounded |
|
|
Starter: |
24V,5.4KW |
|
|
Alternator |
28V,758W |
|
|
Battery voltage |
12V/165Ah |
|
Frame |
Strengthen steel frame, designed according to tough road condition. |
|
|
Tyre |
10+1 spare tyre with rim |
|
|
|
12.00R20 radial tyre |
|
|
Suspension system: Strengthen heavy duty Leaf spring type |
||
|
|
Front/Rear |
10/12 |
|
Dump body: type of body : |
||
|
Inside size of Body(mm): 5600x2300x1500, 8mm (floor)x 6mm (side), made of high intensive steel |
||
|
Lifting type: Middle lifter T type hydraulic system |
||
|
Overall dimension(mm): 8629x2490x3450 (Length x width x height) |
||
|
Wheelbase |
3775+1400mm |
|
|
Track: |
|
|
|
|
Front/Rear |
2036/1850 |
|
|
Approach/Departure angle |
28/30 |
|
|
Front /Rear overhang |
1525/850 |
|
|
Max speed |
77km/h |
|
Curb weight: |
12500kg |
|
